The flame sensor is a small but critical component in your Trane furnace — and it is one of the most common causes of furnace problems. A dirty or failed flame sensor causes the furnace to light and then shut off within seconds, usually with a 8-flash fault code (low flame signal) on the control board. The good news: cleaning a flame sensor is one of the simplest furnace maintenance tasks, and it costs almost nothing.
This guide explains how the flame sensor works, how to tell if it is causing your furnace problems, how to clean it, and when it needs to be replaced. For professional service in the St. Louis metro, call Thomas Hoffmann Air Conditioning & Heating at (314) 471-7625.
What Does the Flame Sensor Do?
The flame sensor is a metal rod — typically made of stainless steel — that extends into the burner flame. It works on a principle called flame rectification: when a flame is present, it allows a small AC current to pass through the flame to ground, producing a DC microamp signal. The furnace control board monitors this signal to confirm that gas is actually burning.
Without this confirmation, the furnace would have no way to know whether ignition was successful — it would continue sending gas to unlit burners. The flame sensor is what prevents that dangerous scenario.
A properly functioning flame sensor produces a signal of approximately 1–10 microamps DC. Most Trane control boards require a minimum of 0.5–1 microamp to confirm flame. When the sensor signal drops below this threshold — due to oxide buildup on the rod — the board interprets it as no flame and shuts off the gas valve.
Symptoms of a Dirty or Failing Trane Flame Sensor
- Furnace lights and runs for 3–5 seconds, then shuts off
- This repeats two or three times before the control board locks out
- 8-flash fault code on the Trane control board (low flame signal)
- 2-flash lockout code after repeated failed attempts
- Furnace works fine in the morning but fails later in the day as it heats up (the oxide layer increases resistance as it heats)
How to Clean a Trane Furnace Flame Sensor
Tools needed: Screwdriver (typically 1/4-inch hex or Phillips), fine steel wool or 400-grit emery cloth, clean cloth or paper towel
Important: Turn off power to the furnace at the power switch AND the circuit breaker before working inside the furnace. Allow the furnace to cool if it has been recently running.
- Step 1 — Locate the flame sensor: Remove the lower access panel on the furnace. The flame sensor is a metal rod mounted near the burner assembly, connected by a single wire with a wire connector. It is usually held in place by a single screw.
- Step 2 — Disconnect and remove: Unplug the wire connector from the sensor terminal. Remove the mounting screw and carefully slide the sensor out. Note how it is positioned — you will reinstall it the same way.
- Step 3 — Clean the rod: You will likely see a white or gray oxide coating on the metal rod. Using fine steel wool or 400-grit emery cloth, gently rub the rod until it is shiny. Work only on the metal rod portion — do not sand the ceramic insulator or the connector. Wipe clean with a dry cloth.
- Step 4 — Reinstall: Slide the sensor back into its bracket in the same orientation, tighten the mounting screw snugly (do not overtighten — the ceramic can crack), and reconnect the wire.
- Step 5 — Restore power and test: Replace the access panel, restore power, and call for heat. The furnace should now light and run through a complete cycle.
When to Replace the Flame Sensor Instead of Cleaning It
Cleaning resolves the problem in most cases. Replace the flame sensor when:
- The rod is pitted, corroded, or physically damaged
- The ceramic insulator is cracked
- Cleaning resolved the problem but it returned within one heating season
- A technician has tested the sensor and confirmed the microamp signal is below spec even after cleaning
Trane furnace flame sensors typically cost $15–40 for the part. The replacement procedure is the same as cleaning — remove, swap, reinstall. Make sure the replacement sensor matches the original mounting configuration.
How Long Do Trane Flame Sensors Last?
A flame sensor in good condition can last the life of the furnace. However, in areas with higher humidity or homes where the furnace runs heavily, oxide buildup can occur more quickly. Annual furnace maintenance typically includes flame sensor cleaning or inspection, which prevents the problem from occurring mid-heating season.
Trane Flame Sensor Service in St. Louis
If you are not comfortable working inside your furnace, or if cleaning the flame sensor did not resolve the problem, Thomas Hoffmann Air Conditioning & Heating can diagnose and repair it. We also offer annual furnace maintenance that includes flame sensor inspection as part of our standard service. Call (314) 471-7625 to schedule.
Related: Trane furnace fault codes — 8-flash (low flame signal) | Trane furnace won't ignite | Trane furnace short cycling
